Combination Antenna




Model No. AM460GCREBCM20B
GPS(1575.42MHz)
Iridium(1616~1626MHz) N/AN/A
LTE(696-800MHz) N/A
AMPS(804~896MHz) N/AN/A
GSM(824~960MHz)
DCS 1800(1710~1880MHz)
PCS 1900(1850~1990MHz)
WCDMA(1920~2170MHz) N/A
2.4G N/A
5G N/A
Weight(without Cable) 680 grams max. 280 grams max. 75 grams max.
Dimension 139mm Dia. x 60mm100mm Dia.× 67mm (39mm+28mm)75mm Dia. x 16mm
Waterproof IP67IP56IP67
Mounting Permanent mountPermanent mountMagnetic mount
Top Housing Material ASAABSASA
Bottom Material Stainless Steel(SUS304)ABSASA
Nut Material Stainless Steel(SUS304)ABSN/A
