EOL GPS Antenna




Product Type M827B/M820B/M812B/M535C/M335C/M828T/M828S/M840CL312B/L320B/L327B/L512B/L520B/L527B/L828TU535C/U335C/U827B/U820B/U812B
Frequency 1575.42 ± 3 MHz1575.42 ± 3 MHz1575.42 ± 3 MHz
Peak Gain at 0° (7cm x 7cm ground plane) 4dBic Min.4dBic Min.4dBic Min.
Amplifier Gain without cable 12dB to 40dB depend on model12dB to 28dB depend on model12dB to 35dB depend on model
Noise Figure 1.4 to 2.0 depend on model1.5dB Typ.1.4 to 2.0 depend on model
DC Voltage 2.7 to 6 V depend on model2.7 to 6 V depend on model2.7 to 6 V depend on model
DC Current 3.5 to 25mA depend on model5 to 22mA depend on model3.5 to 22mA depend on model
Housing Material ABS+PCPCASA
Weight(without Cable) 42 grams max.46 grams max.42 grams max.
Dimension 48 x 40 x 13mm50 x 50 x 17mm49 x 36.6 x 15.8mm
Waterproof IP56IP56IP67
