Iridium Antenna




Model No. MPIDMCMIDMGCRGI
Iridium Certification
Iridium
GPS N/AN/A
Iridium Center Frequency 1621 ± 3 MHz1621 ± 3 MHz1621 ± 3 MHz
Bandwidth 20 MHz Min. at -10 dB20 MHz Min. at -10 dB20 MHz Min. at -10 dB
Axial Ratio 3dB Max. @ 0°3dB Max. @ 0°3dB Max. @ 0°
Efficiency 70% Min. (Without ground plane)70% Min. (Without ground plane)70% Min. (Without ground plane)
Impedance 50Ω50Ω50Ω
Peak Gain 4dBic Min @ 0°4dBic Min @ 0°5dBic Min. @ 0°
Polarization RHCPRHCPRHCP
GPS Center Frequency N/AN/A1575.42± 3 MHz
Gain Coverage N/AN/A4dBic Min.
Amplifier Gain N/AN/A≧ -4dBic at –90° ≤ θ ≤ 90°(over 75% volume)
Filtering N/AN/AAt ±40MHz 35dB; At ±75MHz 40dB; At ±100MHz 45dB
DC Voltage N/AN/ADC 2.7 V to 6.0V
DC Current N/AN/A12 ± 5.5 mA
Housing Material ABS+PCASAASA
Housing Color BlackBlackWhite
Weight (Without Cable) 42 grams Max.75 grams Max.280 grams Max.
Dimension 48x40x13mm75mm Dia. * 15.8mm100mm Dia.× 67mm(39mm+28mm)
Connector CustomCustomCustom
RF Cable CustomCustomCustom
Cable Length CustomCustomCustom
Mounting Magnetic baseMagnetic basePermanent mount
Degrees of Protection IP67IP67IP67
