Model No. | LHR10 | LSS10 |
Functions | LoRa Receiver | LoRa Sensors:PM2.5/ PM10 Sensor;Humidity/Temperature Sensor |
Hardware Specifications | ||
| Controller | ATmega328/P | ATmega328/P |
| Operating Voltage | USB power In 4.5~5.2V | 12V cable in |
| LoRa® Chipset | SX1276 | SX1276 |
| LoRa® MCU | STM32L151 | STM32L151 |
| Frequency | 902 - 928 MHz | 902 - 928 MHz |
| Transmitting Power | 902-928 MHz@20 dBm | 902-928 MHz@20 dBm |
| Transmitting Distance | 1~10 KM @0.81 Kbps | 1~10 KM @0.81 Kbps |
| Receiving Sensitivity | -132 dBm @0.81 Kbps | -132 dBm @0.81 Kbps |
Mechanical Specifications | ||
| Dimension | 59.05(L) × 54.92(W)x 24.88mm(H) (Metal Box with ear) | 72.62(L) × 45.7(W)x 41.2mm(H) (Metal Box) |
| Connector | RJ45, Micro-USB, LoRa Antenna | Micro-USB, LoRa Antenna |
